| Frameset |
|
Alpha Silver Aluminum, curved top tube, internal derailleur & dropper post routing, rack and kickstand mount, 135x5mm ThruSkew
|
|
SR Suntour XCM 30, coil spring, preload, hydraulic lockout, 42mm offset for 26'' wheel, 100mm QR, 100mm travel
|
|
None
|
| Drivetrain |
|
Shimano M315, 8 speed
|
|
ProWheel alloy, 30T narrow-wide steel ring, 160mm length
|
|
Threaded cartridge
|
|
None
|
|
Shimano ESSA U2000
|
|
Shimano HG300, 11-45, 8 speed
|
|
KMC Z8.3, 8 speed
|
| Brakes |
|
Tektro HD-M276 hydraulic disc
|
|
Tektro HD-M276 hydraulic disc
|
|
Tektro, 6-bolt, 160mm
|
|
Not listed
|
| Wheels and Tires |
|
Bontrager Montrose Comp, wire bead, 30 tpi, 26x2.35''
|
|
Formula DC-20, alloy, 6-bolt, 100x5mm
|
|
116x5mm QR
|
|
Bontrager Connection, double-wall, 32-hole, 20mm width, schrader valv
|
|
Bontrager Montrose Comp, wire bead, 30 tpi, 26x2.35''
|
|
Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5mm
|
|
173x5mm QR
|
|
Bontrager Connection, double-wall, 32-hole, 20mm width, schrader valv
|
|
Not listed
|
|
Schrader valve
|
| Cockpit |
|
Bontrager Verse Short, stainless steel rails
|
|
Bontrager alloy, 31.6mm, 12mm offset, 300mm length
|
|
Bontrager alloy, 31.8mm, 5mm rise, 690mm width
|
|
Trek Line Comp, nylon lock-on
|
|
Bontrager Comp, 31.8mm, 7 degree, 35mm length
|
|
Semi-integrated, 1-1/8''
|
|
nylon platform
|
| Weights |
|
M - 14.90 kg / 32.85 lbs
|
|
This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg).
|
