Trek Checkpoint SL 5 Gen 3 AXS Road Bike Black/Matte Carbon Smoke
Trek Checkpoint SL 5 Gen 3 AXS Road Bike Black/Matte Carbon Smoke
SKU:210000018666
Regular price
$3,499.00 USD
Regular price
$3,499.00 USD
Sale price
$3,499.00 USD
Unit price
/
per
Shipping calculated at checkout.
Low stock: 1 left
Couldn't load pickup availability
Have a question about this product?
Have a question about this product?
Share





Checkpoint SL 5 AXS Gen 3 is an adventure-ready carbon gravel bike built to roll into the distant horizon. Its lightweight carbon frame is designed with comfort-focused geometry, room for beefy 50mm tires (as measured), and plenty of frame and fork mounts. Plus, IsoSpeed comfort technology helps soak up jarring road vibrations, so you can you float over chatter and potholes. It comes equipped with a wireless SRAM Apex XPLR AXS drivetrain to deliver plenty of gears for exploring the dusty road.
Why you'll love it:
- Checkpoint's Gravel Endurance geometry lets you sit higher up and features a shorter reach to keep you comfortable on all-day gravel adventures, light singletrack, bikepacking trips, and more
- Road-smoothing IsoSpeed comfort tech soaks up vibration from rough surfaces to keep you feeling fresher longer
- A SRAM Apex XPLR AXS 12-speed drivetrain offers precise, fully wireless shifting that's made for the roughest roads
- Clearance for 50mm tires (as measured) means you can add extra traction and cushion for rowdy gravel roads
- You can haul it all with large internal frame storage and mounts galore on the frame and fork for hydration, front and rear racks, fenders, and Adventure Bags that were designed to perfectly fit Checkpoint
Specifications | |
---|---|
Bike Name |
Trek Checkpoint SL 5 Gen 3 AXS
|
Electric Assist | |
Electric Assist |
No |
Class |
Not Applicable
|
Motor |
None
|
Throttle |
No |
Display |
None
|
Battery |
None
|
Charger |
None
|
UL Certified |
No |
Frameset | |
Frame |
500 Series OCLV Carbon, IsoSpeed, downtube storage door, hidden fender mounts, rack mounts, integrated frame bag mounts, RCS Headset System, invisible cable routing, T47, flat mount disc, integrated chainkeeper, removable FD hanger, UDH
|
Fork |
Checkpoint full carbon, tapered carbon steerer, fender mounts, triple rack mounts, flat mount disc
|
Rear Shock |
None
|
Drivetrain | |
Shift Levers |
SRAM Apex AXS, 12 speed
|
Crankset |
SRAM Apex 1, 40T, DUB Wide
|
Bottom Bracket |
SRAM DUB Wide, T47 threaded, internal bearing
|
Front Derailleur |
None
|
Rear Derailleur |
SRAM Apex XPLR eTap AXS
|
Cassette or Cog |
SRAM XPLR PG-1231, 11-44, 12 speed
|
Chain |
SRAM Apex, 12 speed
|
Brakes | |
Front Brake |
SRAM Hydraulic Disc Brake
|
Rear Brake |
SRAM Hydraulic Disc Brake
|
Rotors |
SRAM Paceline, rounded, centerlock, 160mm
|
Brake Levers |
SRAM Apex
|
Wheels and Tires | |
Front Tire |
Bontrager Girona RSL, Tubeless Ready, GR puncture protection, aramid bead, 220 tpi, 700x42mm
|
Front Hub |
CL-712 Centerlock Disc hub, 24H
|
Front Axle |
Bontrager Switch chamfered thru axle 100x12mm, removable lever
|
Front Rim |
Bontrager Paradigm SL TLR rim
|
Rear Tire |
Bontrager Girona RSL, Tubeless Ready, GR puncture protection, aramid bead, 220 tpi, 700x42mm
|
Rear Hub |
CL-712 Centerlock Disc hub, 24H
|
Rear Axle |
Bontrager Switch chamfered thru axle 142x12mm, removable lever
|
Rear Rim |
Bontrager Paradigm SL TLR rim
|
Spokes |
Black
|
Tube Type |
Presta
|
Cockpit | |
Saddle |
Verse Short Comp, steel rails
|
Seatpost |
Bontrager carbon, 27.2mm, 8mm offset, 330mm length
|
Handlebars |
Bontrager Elite Gravel, alloy
|
Grips/Bar Tape |
Bontrager Supertack Perf tape
|
Stem |
Bontrager Elite, 31.8mm, Blendr compatible, 7 degree
|
Headset |
Yes
|
Pedals |
None
|
Weights | |
Bike Weight |
20.95 lbs (ML)
|
Rider Weight Limit |
275 pounds
|
